Smart power controlling board
IQboard mobile is smart home power controller for DYI users and service providers. Suitable for sites which require remote control power of electrical equipments. They can be controlled from any reason such as freezing, time-based power control, overheating or other. Power can be controlled by phone, tablet or computer according to collected information from external sensors. Easily over SMS, phonecall, voice-navigated call or Bluetooth.
- Two controlled power outputs
- Turn on / off, turn on/off for defined time, restart
- On event power control
- Scheduled power control
- Control by mobile phone, tablet or PC
- Power outage monitoring
- Built in two digital inputs
- High level of data security
- Actions on alarm events
- Designed for DYI installations
- Support external digital sensors
IQboard was designed as power controlling plattform for DYI installations and small service providers. If you love playing with technical miracles or just need simple HW solution with robust software features for your service plattform, IQboard will serve you very long time for very affordable price.
Access from everywhere
Smart IQboard can be simply controlled remotely by traditional phone, mobile phone , smartphone, tablet or traditional PC. Controlled by SMS, voice navigated phonecall, smartphone comfortable application or PC.
Power status, power outage, sensor generated events and other alarms are sent over SMS. IQboard generate triggered alerts to notify user about events and run appropriate actions.
Control different ways
Two power outputs can be controlled remotely by user, built-in scheduler or an event. Power control consist of many optionable actions such as: turn on/off, on/off for configured seconds, restart, actions scheduling and more.
Expandable with sensors
Power controller support many optional sensors to monitor environment and generate alarms on preconfigured events. Supported are external sensors like temperature / humidity / motion / smoke / gas detectors / door switch and more.
- Smart house power control
- Gate control
- Garden irrigation control
- Power outage monitoring
- WISP on-tower wireless control
|Input power||8 – 24V AC/DC|
|Output relay||2 x up to 230V AC/16A – resistive load designed also for purpose of inductive load switching (motors,transformers) to increase relay lifetime cycles|
|Data interfaces||GSM SIM socket – Plugin 3V, Bluetooth 2.0|
|Inputs||two digital inputs 0-30VDC, detection threshold 2V|
|Control and configuration||SMS, Bluetooth, IQcontrol software or voice navigation|
|Indicators||POWER: red LED | GSM: green/red LED OUT1,2: yellow LED DIG.INPUT1,2: green LED|
|GSM||Quad band 850 / 900 / 1800 /1900 MHz external SMA(f) connector + 1dBi ant included|
|Installation category||Class II., overvoltage of max.3000 V|
|Operation temperature||-10 .. +50 C|
|Operation humidity||max. 80%|
|Supercapacitor lifetime||1 mil. charging cycles, up to 3 years at 25 C|
|Dimensions||83 x 73 x 25 mm|
Control software for Android on Google Play – IQcontrol
Sample of Voice navigated message #1
Sample of Voice navigated message #2
